Overview
The QSC K.2 Series represents the best-inclass loudspeaker for today’s demanding audio professionals. The perfect combination of elegant design, superior audio performance, high functionality, simple and intuitive operation, and genuine QSC reliability, K.2 delivers extraordinary results for users in both portable and installed applications.
Features
Best in class audio performance
2000 Watt Class-D amplifier module
Intrinsic Correction™ tuning and loudspeaker management
DMT™ (Directivity Matched Transition) design provides excellent power response and consistent performance across the listening are
Refined, professional appearance looks great in any application
Rugged ABS enclosure for long life and lasting durability
Deployment in either main PA or floor monitor position
Factory Presets and savable/recallable Scenes for commonly-used application
Multi-function digital display for control and selection of loudspeaker functions including cross-over, EQ, delay and frequency contour
Dual pole cup mounts (standard and 7.5 degree down-tilt)
M10 fittings for flown applications
Optional security panel prevents unauthorized tampering of controls
Complete EASE and CAD information available online
6-Year Warranty (with product registration)
Configuration Multi-purpose, 2-way powered loudspeaker
LF Transducer 12" (305 mm), cone
HF Transducer 1.4" (35.6 mm) titanium diaphragm compression driver
Frequency Response (-6 dB) 50 Hz - 20 kHz
Frequency Range (-10 dB) 45 Hz - 20 kHz
Nominal Coverage Angle 75° Axisymetric
Maximum Rated SPL1
Amplifier
Cooling 132 dB @ 1 M, peak 126 dB @ 1 M, continuous
Class D
Peak: 1800 W (LF), 225 W (HF)
Low-noise, variable speed fan
Controls Power
3 x Level
Rotary encoder (push)
2 x selection buttons
Indicators Monochrome LCD Display 1.75" x 1" (45 mm x 25.4 mm)
2 x Power LED (front and rear)
3 x Input Signal LED
Input A Mic selected LED
Input B Hi-Z selected LED
Limiter active LED
Connectors 2 x locking XLR/F ¼" combo (Mic/Line Input and Hi-Z/Line Input
1 x 3.5 mm TRS (Stereo Input)
2 x XLR/M (Loop-thru Output)
1 x XLR/M (Mix Output)
1 x locking IEC power connector
AC Power Input Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption 1/8th Power2 100 VAC, 2.1 A / 120 VAC, 1.9 A / 240 VAC, 1.1 A
Enclosure Details
Enclosure Enclosure Impact Resistant ABS
Attachment Points 2 x M10 threaded inserts plus Pull-Back
Color Black (RAL 9011)
Grille 18 Gauge powered coated steel, internal cloth lining
Dimensions (HxWxD) 23.7 x 14 x 13.8 in
602 x 356 x 350 mm
Net Weight 17.7 kg (39 lbs)
Shipping Weight 21.7 kg (47.8 lbs)
Regulatory CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
Optional Accessories K12 Tote, K12 Outdoor Cover
M10 Kit-C, K.2-LOC LockOut Cover
K12.2 Yoke
